Sale: 14"-24" Heavy Duty Steel Column Forms

In stock
Only %1 left
SKU
HDS 14-24
Select for Price

**Prices are for NEW forms. Please check with Customer Service for pricing and availability of USED forms.**

CAT#:  Example HD2496

            First two digits= form diameter... 24" dia

            Second two digits= form height...96 " or 8ft





Deslauriers Heavy Duty Steel Column forms develop an exceptionally smooth, hard surface remarkably free of voids and with a minimum number of indistinct seams. The forms are galvanized constant radius steel half round sections and quarter round sections (for forms over 48" in diameter) bolted into units for crane handling on the jobsite.

Vertical and horizontal seams, opened and closed with each pour, are connected with high speed bolts to speed setting and stripping.

In addition to the standard column diameters shown, custom diameters and lengths are also available.

Lateral pressure should not exceed 3000 PSF on forms through 36" diameter or 2000 PSF on forms over 36" diameter.

Built-in 1-1/2" lifting holes on most 4ft and 8ft forms. Lifting design of 4000 pound per hole or 8000 pounds assembled. Deslauriers recommends using lifting spreader bar for lifting all column forms.
